Voltage Sensor for Cellpack CTS-S 630 VxxxJC

APPLICATION

The VxxxJC voltage sensor (LPVT) is a passive, non-conventional voltage sensor with a long type-C cone, shaped for the Cellpack CTS-S 630 T-connector in gas-insulated medium-voltage switchgear. It replaces the blind plug of the T-connector and serves both to secure the connector in place and to measure voltage. The sensor has a point for common earth connection and an output cable for connection with an intelligent electronic device (IED).

PRODUCT ADVANTAGES

• Passive components – no power supply needed
• Compact form factor – length of a standard blind plug
• Robust design – Tightening cap made of solid metal alloy
• Long type-C cone shaped for Cellpack CTS-S 630
• Wide temperature range

TYPES OF CABLE CONNECTION   Symmetric T-connector / deadbreak
